5/2 configuration for double-acting actuators.Deenergized state, with supply to port 1, flow is directed to port 4 and port 2 is vented to atmosphere via port 3.
Features
|
- |
Explosion proof coils, CSA certified and FM approved for hazardous locations: |
|
|
|
|
-
|
Coils easily changed with a wide selection of voltages available. Other Ex and ATEX options available.
|
|
-
|
Robust, Reliable and Compact design provides bubble-tight shut-off and high cycle life. |
|
-
|
Corrosion resistant construction with standard manual override. |
|
-
|
Direct mounting conforms to Namur VDI / VDE 3845 standard. |
|
-
|
5/2 and 3/2 function selectable via 180° rotation of single adapter plate. |
|
-
|
Exhaust feedback - provides spring chamber with instrument air preventing corrosion. |
|
- |
Wide operating temperature range -4°F to +140°F [-20°C to +60°C]. |
